Inside cab view - The control stand for MoPac SD40-2c #6044 - Jay Glenewinkel Photo

From Behind the Throttle
The Engineer's Perspective
Compiled/Written by T. Greuter

Take a seat behind the throttle controlling 1,000 horses, and see what real railroading is -- from the MoPac Engineer's seat.

The People
Our aim here is to share the stories about the MoPac Employee, as well as the nuts and bolts of railroading, all from the point of view of the people that ran it. It's something that you rarely find too much of on the Web. We feel there should be more attention on the former employees, who tell of their lives on the railroad in their own words.

There are two individuals who have contributed greatly to this project, who I'd like to personally thank - Bob Currie and Tuch Santucci.

JD "Tuch" Santucci, a former MoPac Engineer, has generously allowed me to quote many of his stories and is a frequent poster at the MOPAC group on Yahoo and publisher of his own online newsletter, "Hot Times on the High Iron" -- it is always worth stopping whatever you're doing to read.

Bob Currie, also a former MoPac Engineer that I've frequently corresponded with has built an excellent website filled with experiences of railroad life. Bob probably has more tales to share than he will ever get written down.

The Machines
There's more to a locomotive than the engine itself... there's the sounds and vibrations and smells that tells you she's alive... The bellow and snort of a steam driven engine and the growls or whines of a diesel prime mover (Alco, EMD, GE, etc.), the blare of air horns (combinations limited only by imagination), a ringing brass bell. There's the brakes and an array of guages and switches which you must know each by heart... the steamer crew also had the hungry Firebox to feed and the mighty Johnson bar.

There's the sharp pitch of flange squeal that can rattle your teeth. There's soot and smoke and grease. There's hot steam, compressed air and the acrid fumes of diesel fuel being turned into power to pull a train a mile long. Being a member of the crew means that you understand this beast of burden as if it where a living, breathing animal. You know how to force this dangerous and stubborn beast to perform at your command.

The crew pose with pride with Missouri Pacific #152 for the camera at Hermann, Missouri in 1877. Though all are unidentified, it is clear everyone wanted to be included in the historic moment. - W. A. Anderson Photo / T. Greuter Collection

The Stories
There's is nothing that breathes more life into history than the firsthand accounts of those people involved. Twenty years after the MoPac was swallowed-up, it's an unfortunate fact that so much has been lost already. The railroaders were people just like you and me, were asked to do much for little pay. Their stories are filled with danger, sometimes tragedy. Yet they retained their good humor, in fact practical jokes and playing pranks on one another was all part of being a member of the rail crew.

We will continue to add more stories as told by former employees of the Missouri Pacific, material by engineers, and any interesting information we come across. Enjoy!

Many of those who have contributed have their own excellent websites and organization -- we've provided links to some of these sites at the bottom - we highly recommend that you pay each a visit.

From Behind the Throttle
JD "Tuch" Santucci

While most didn't know it, MoPac was very quietly and conservatively one of the richest railroads in North America. It was indeed a great railroad. I was fortunate and got to operate all the new power as most of it was delivered to Yard Center and placed into service there.

Favorites for road power were the SD40 series. In the yard the GP15 and MP 15 series and the GP38 series for much of everything else.

I didn't care for the B23/30 series as their ride was extremely rough and would about kill your kidneys, although they did pull well on dry rail.

The U30C's were bastard red-headed step children that were real oddballs and poorly maintained as a result. They seemed to be prone to failure.

The GP50's were pretty good high speed units, but were poor performers on heavy tonnage trains. They tried them on some coal trains with dismal results including burning up main generators and traction motors.

The GP15-1's actually had some remanufactured components. They required a trade in unit towards them. This lowered their purchase price and also offered the MoPac some tax breaks on the price of them as well. I liked them as they were really good units and performed well. Their only drawback was that some of them seemed to have excessive vibration when idling in regular idle.

JD "Tuch" Santucci is a former MoPac Engineer, having worked in Dolton and Villa Grove, IL from 1978 to 1985. Today Tuch is still associated with railroading, as an engineer on the CNIC and producing his own newsletter Hot Times on the High Iron. Many of the stories on this page came from Tuch's newsletter -- I highly recommend signing -up for a subscription yourself!

Visit the BLE Division 10 Web site at http://div10.tripod.com/homepage.html

The MoPac in Chicago - "Tuch" Santucci in October 1981 at Yard Center, Chicago.

Rail Terms and Slanguage
Bob Currie

Names for the caboose included hack and crummy.

The switchman (or head brakeman on road trains) that pulled the pins during switching operations was called the pin man.
The switchman (or rear brakeman on road trains) that lined the switches and caught handbrakes during switching operations was called the field man.

If a crew kicked cars during switching operations, that was called "flat switching". If cars were shoved over a mound (hump) and the cars rolled down into tracks under their own momentum, that was called hump switching.

Another name for train orders was "flimsies."

A yard clerk was called a mud hop (I started my railroad career as a mud hop).

On a freight train, the conductor is in charge of the work on the ground. On a switch engine, the footboard yardmaster is in charge of the work on the ground.

Powerbraking - The Missouri Pacific did not have dynamic brakes on its engines. The MOP was a powerbraking railroad.

The engineer kept a steady hard pull on the train with his engine, often leaving the engine in run 8 almost to a stop. If you had a train running 50 mph, if the throttle was not in run 8, you put it in run 8, and then about 1.5 to 1.25 miles from where you wanted to stop you made a 6-pound reduction of the train line. The MOP carried an 80-pound trainline on its freight trains. Some railroads carried the minimum 70 pounds, while many carried the maximum 90-pound trainline. A 6-pound reduction made with the automatic brake valve (keeping the engine brakes released) caused the car brake valves to put 15 pounds of pressure into each car brake cylinder. Each additional pound of trainline reduction put 2.5 pounds of pressure into the car brakecylinders. After making the initial reduction of 6-8 pounds, we followed with 2-pound reductions.

Often, a 6-2-2 combination was sufficient to stop a 100-car train in 1.25 miles, even with the engine pulling hard to keep the train stretched. We had a saying for when we got a knuckle- "I got 6, 2, and 2, and when I stopped I was in two." I told that to the road foreman of engines on the occassion of my getting 2 knuckes at once, and he made me drive 150 miles to Baton Rouge to discuss it after I tied up.

The advantage of power braking was that it was very smooth for the people riding the caboose- no slack action. Also, when we started the train moving, you could put the engine in a much higher throttle position, say run 4, because as soon as the engine moved, the caboose moved. I have had a train so tight that my engine moved only 1 foot and the conductor said "all moving." With the new EMD power (GP35s, GP38s, and SD40s), you could start a train without having to take slack. On a long, heavy train with the GP7s and GP9s, and sometimes with the GP18s, you may have to take slack to get the train moving. When taking slack, you either took just a little (4 or 5 cars), or you took slack on the whole train. This was so prescribed in the Air Brake and Train Handling Instructions, and was on the engineer's exam.

Wheel slip was an engineer's worst nightmare when starting a train. If the wheel slipped and then grabbed, the train would be yanked in two if you were not quick on reducing the throttle. We always stopped the engine on sand (except within interlocking limits) so that we would have some good traction when starting.

More Rail Slanguage (picked-up from numerous sources):

ABS - automatic block signal. This is a system for controlling trains. The track is divided into a series of blocks which are controlled by block signals activated by the presence of a train.

A-unit - a normal locomotive that has a control stand (different than a B-unit). Normally only used to differentiate a locomotive from a B-unit where they may share a similar body or engine. F7 locomotives were made in both A-unit and B-unit styles, for example.

Anti-climber - ridge on the front of a locomotive so that in case of a collision with another vehicle, it doesn't ride up into the locomotive cab

B-unit - locomotive which has a diesel engine and generator but no cab.

Covered Wagon - a cab unit, or more generally, a fully cowled locomotive.

Cowl - the covering over the working parts of the locomotive. A fully-cowled locomotive has no walkways on the outside; the long hood extends straight back from the cab.

CTC - centralized traffic control. This is a system of track control where an RTC controls the signals and switches along the track and thus controls the trains on it.

Belt Line - A railroad with trackage within and/or around a city, operating as a pickup, delivery and transfer facility for truck lines and industrial plants.

Block System - A system of railroad tracks divided into short sections or blocks, usually three or four miles in length, which will permit trains to be run by signal apparatus so that no train can enter a block until the preceding train has left it.

Branch Line - A line serving one or more stations beyond the point of junction with the main or another branch line.

Chain Gang - When a number of extra trains (not regularly scheduled freight runs) are put into service, regular crews may be assigned to take such trains in turn. When this occurs, train crews are said to be operating in chain gang service.

Dead Head / Dead Heading - A railroad employee traveling as a passenger. The employee performs no service in such travel status, and he/she is paid for his/her time while in travel at an hourly "dead head" rate.

Dog chasing - A crew change out.

Double the hill - the train is split in half to get up a grade.

Double Track - Two main tracks, one of which the trains run in one direction and the other in the opposite direction.

Drag - Describes the movement of a heavy train, such as a coal drag

Dump the air - Emergency application of the air brakes causing a train to stop abruptly

Extra Board - A list of employees who may be assigned to train crews (1) when extra trains are run, (2) when regular crews have not had sufficient rest time before they can legally be required to return to duty, or (3) when relief men are required on regular crews.

Foamers - people who gathered along the tracks to watch trains.

Gauntlet - A third set of rails placed in between two other sets of rails to carry wide loads through tunnels.

Grip - Trainman's suitcase

Guinea - Usually a new worker unfamiliar with job requirements.

Highballing - Running at maximum permissible speed

Hole - Side track on a single track line which permits another train to pass.

Interchange - to move a rail car or locomotive from one railway to another. This usally takes place at an "interchange point".

Ladder track - series of turnouts leading to parallel tracks

Livery - paint scheme, manner in which equipment is painted (e.g. stripes, bars, colours, logos), usually for a locomotive

Mainline - a.k.a main, iron, high iron, high rail

Mosey Speed - means when you approach the limit of your track warrant and have not received a new warrant, you mosey up to the limit prepared to stop.

MU - multiple unit; slaving of two or more diesel electric locomotives together, controled from the control stand of only one of them, usually the lead locomotive.

No Bill - A worker who refuses to join the union, particularly train or enginemen.

Pig train - intermodal train, originally piggyback

Piggyback - occurs when a tractor trailer is placed (usually without the tractor) on a flat car or specially-designed rail car. See also TOFC.

Prime mover - drives a generator which produces electrical power to drive the traction motors. There is usually one traction motor on each axle.

Pull the pin - uncouple

Put it on the ground - the train has derailed

Pusher - a locomotive built to help trains up steep grades by pushing from behind
- OR - Team leader responsible for seeing that work gets done on schedule.

Ran a Red Block - Enter a circuit without clearance from the control tower.

Red Ball - A fast freight train.

Siding - An auxiliary track along the main line which is used to permit other trains to pass. (See Hole.)

Spark arrester (arrestor) - device on the exhaust of a locomotive to keep sparks from flying out and starting fires. These are often quite distinctive on MP equipment.

Spot - park a rail car.

Steam generator - equipment to generate steam to heat passenger cars in the early age of diesel. Some diesel locomotives have steam generators in them; steam was passed to the attached passenger cars by interconnected pipes.

TOFC - short for Trailer On Flat Car; when a tractor trailer is placed (usually without the tractor) on a flat car or specially-designed rail car.

Trick - A work shift or hours of duty.

Turn-Around - A train run from a terminal to an intermediate station and return to that terminal in one work shift.

Varnish - private railroad passenger car, a.k.a "private varnish"

Winterization Hatch - baffle placed over the radiator fan on some locomotives used in colder climates to retain heat in the locomotive

Throw it in the hole - Apply emergency brakes.

On the high iron, let the big dogs walk - the caboose is over the switch and on the mainline so open the throttle all the way on the locomotives

All black, well stacked, goin' down the track clickity clack - the train looked good on the visual roll-by inspection.

Related Links:

• Visit Bob Currie's NEW rail blog for his photos and many stories.

Controlling One-Thousand Horses

An engineer may work daytime or night -- the railroad never sleeps.

To become a locomotive engineer, the trainee begins by pushing and pulling cars back and forth and making up trams in railroad yards with a Switch engine. After proving himself with this assignment he moves on to a local freight run. Finally, with more experience and seniority, he'll earn a fast or long distance freight or passenger run.

The engineer's left hand is on the throttle, by which he controls the speed.

To start the engine, he releases the air-brakes and pulls the throttle slowly toward him.

To stop the engine, he applies the air-brakes and moves the throttle in the other direction.

Braking takes considerabe time and distance to stop a train which can be a mile-long. For braking, the engineer releases sand when it is needed to prevent the wheels from slipping on the rails.

The engineer is also responsible to signal his train crew and sounds warnings upon approaching crossings, stations and persons or animals on the track.

When the train is approaching a grade crossing or a station, the engineer sounds a few blasts on the engine's horn (MoPac liked to use 3-chime Leslie airhorns on most modern diesels) by pushing a button.

The engineer also uses the brass bell (usually mounted high behind the cab) which rings slowly as the engine moves at slow speeds or reverse direction.

Practical Jokes and Railroad Mayhem - Just Looking for the Tosh
"Tuch" Santucci - from Hot Times on the High Iron

Another character at the MoPac was known as "The Tosh." This was a play on his last name. He seemed to have a few screws that had come loose. Well actually they fell completely out over the years and rolled away. He was about half goofy. He did all sorts of outlandish things on duty. After going out drinking with him one evening after work, I learned that he was the same way outside the railroad too. I also quickly learned that one should never go out drinking with him either. I didn't think I was going to make it home alive.

He said and did all sorts of insane and goofy things. A fellow employee had a great deal of fun with his nickname and applied it to the "Kilroy was here" drawing of the guy with the large proboscis looking over the fence. He drew this picture and wrote "Just looking for the Tosh". He drew it on almost everything: walls, rolling stock, in the dirt on the side of company vehicles. I once saw it on the side of a Carmen's shanty in Fort Worth, TX while riding Amtrak. The Tosh was now universal.

While working a night switcher in 8 Yard at Yard Center with Tosh one evening, we had to switch out some retired Seaboard Coast Line locomotives. They were enroute to Pielet Bros. Scrap yard in McCook, IL. Now we never, under any circumstances, to allow locomotives dead or alive to roll free. Rules are made to be broken, right? I can see one of these locomotives in the cut from my vantage point and see that it is next out to be switched. Tosh gives me a kick sign. WHAT? I didn't move. Again he gives the kick sign, only with even more emphasis than normal. I wind them up, the Headman pulls the pin, Tosh gives me the stop signal and I grind them down to a stop. This old locomotive takes off down the lead and zooms into track 14.

I could hear the crash in my engine as the old locomotive clobbered the cars already in the track. While nothing derailed, the car the locomotive hit was damaged. We never even filled out wreck reports over the situation.

One evening Tosh has to swing a cut of cars over from TwoYard to Nine Yard at Yard Center. This required a long shove and part of that shove involved a couple of road crossings. As fate would have it, the rear car was a load of farm tractors. This car would be leading the movement as they shoved south across the interlocking at 144^th Street and over the two road crossings involved.

Tosh, deciding he really needed to light things up in the darkness of the late evening resorts to extraordinary measures. He proceeds to turn on all the lights on all the tractors loaded on this flatcar. He then lit two fussees placing them on the very south end of the car and when they got the signal, instructed the Engineer to start shoving the cut south. We were pulling out of the north end of a track in One Yard and were able to observe this first hand.

Here comes the cut across 144^th Street with two fussees glowing in their pinkish flame, all the headlights and tail lights illuminated on every tractor on the car, and Tosh sitting in the seat of the very south tractor. He looked like King Farook. It was quite the sight to behold. As he passed us, he casually waved as if this was something he did on a daily basis. We were laughing our heads off.

Practical Jokes and Railroad Mayhem - Company Phone Calls to Hawaii
"Tuch" Santucci - from Hot Times on the High Iron

And yet another character on the MoPac was a Trainman named Marshall. He was right ahead of me in seniority on the Trainman's list. Being that our Trainman's extra board was a seniority board, this was actually to my advantage. He was notorious for taking calls, then either marking off at the last minute or not showing up and then calling in saying he couldn't make it. This would give me a late call to work his assignment. It also meant I got paid from when the job went on duty, no matter what time I arrived. On one occasion he even called in late and told the Caller he was in jail. They checked it out and found out he really was too. It was unfortunate that he wasn't kept there.

This guy had a girlfriend who was on vacation in Hawaii. While she was gone, he had landed the afternoon switcher at 26^th Street Yard in Chicago Heights. Every afternoon he would arrive a few minutes early and call her in Hawaii from a company phone at the 26^th Street Yard office. When the job went to coffee, again he would call her in Hawaii. This was also the case for lunch break and then when the job tied up. He did this for a good week.

Sometime later when the phone bill arrived, those in charge about had a stroke. Here were dozens of calls to Hawaii. It is highly unlikely the MoPac would have any reason to transact business between their 26^th Street Yard and the 50^th state. It was a good bet the powers that be would begin to investigate this bill rather thoroughly. And they did.

It took them a few weeks, but they were able to use the process of elimination to nail Marshall as the culprit of these phone calls. He was made to reimburse the company for all the calls, over $300 worth.

"I am here to save the day"

Reportedly seen bustling around North Little Rock in the late '70's and early '80's, a GP7 with Mighty Mouse on it's side has the distinction of having it's own mascot. MoPac railcrews had their share of practical jokers, and one such joker applied the cartoon to the long hood of MP #180.

Horns & Whistles
"Tuch" Santucci

The 50 Rock Island GP38-2's acquired from the Rock estate all had the Nathan five chime horns. All still had them intact when I left the MoPac in 1985.

An interesting note about these units and their whistles, they had what appeared to be dead man's pedals on the base of the control stand. These pedals were actually connected to the whistles and could be used to sound them instead of pulling the whistle valve. This was a very handy item to have as it freed up a hand when having to brake and sound the whistle at the same time.

Also, a couple of SD40-2C's were retrofitted with a five chimer. If I recall correctly, they were the 6019 and 6047. They had the same model as the Family Lines System (SCL/L&N/Clinchfield/AWP/GA) units built in the late 70's and early 80's had installed at the factories. While I do not know which model of whistle it was, it sure made a great sound, more of a growl than a chime. The whistles on both were in primer red instead of the traditional blue the last time I saw these units in its original blue paint.

I would guess that maybe these units had the whistles damaged while operating in run-through service on the Family Lines and they were replaced with what the shops performing the repairs stocked.

Inside the Cab and other Views

Missouri Pacific locomotive cab interiors - both steam and diesel. The first two shots of steamer #2522 show the engines's firebox, guages, brakes, and the long Johnson bar. The second interior is from an EMD SD40 2 cab, MP #6044, showing the control stand (for a comparison, see view of a 40-2 unit owned by BN, shown in the next group below).

A Chicago Pneumatic speed recorder marks the speed at 50 MPH. This type of speedometer used a roll of paper etched by a stylus to record the speed. They were locked with the same type of lock that appears on Coke machines and were sealed with a numbered seal just like on a boxcar. The seal number was written on the beginning of the roll and checked against the seal number whenever the roll was removed. Notice also the amp gauge below the speedo indicates the unit is loading 350 amps. If memory serves correct, this unit was the 3130. - Tuch Santucci photo

This photo was shot from a MoPac GP7 in 1981. Looking south, on Chicago's 80th Street - J.D. "Tuch" Santucci Photo

A view from the walkway. Looking back at a snow storm while running south on train CH January 1985. A phone pole is barely visible to the right. This was near Glover, IL on the Chicago Sub. - Tuch Santucci photo

The EMD SD40 Control Stand	The AAR-EMD SD40-2 and SD50 Control Stand

Behind the throttle of the MP 6044 in 1984 - Jay Glenewinkel

For more details on locomotive operation, view the Operators Manuals:

• Operators Manual: EMD SD Units
• Operators Manual: GE Dash 7 Units
• Operators Manual: GE B-Boat Units

Cab Views from Other Roads

Though not Missouri Pacific units, we've included these below photos since they may be of interest to the readers of this page - and demonstrate the ever changing world of the Engineer.

SLSF 1522 Steam T. Greuter Photo

BN 1 F-7 T. Greuter Photo

BN 7200 SD40-2 T. Greuter Photo

BN 9620 SD70 MAC T. Greuter Photo

UP 8041 SD90 MAC J. Glenewinkel Photo

More Railroad Stories

In Bob Currie's own words, he is an "A-1" practical joker. You'll enjoy the humorous side of his true stories featured on his website:

• Bob Currie's NEW rail blog

Railroad Employees

Occasionally we receive some great remarks about fellow employees. We've listed some of their names here for the interest of former co-workers:

"... a great hogger, Irv Pupkes. He farms around Falls City, Nebraska and has a step-son, Bob Prichard, who was a Conductor. Both were a couple of the nicest people I've met. And Irv could really handle a train." (James Blagg)
