Historical Wigwag Photos
click to enlarge
SP Permanent local passes the Prospect Rd. wigwag.

Location: San Jose, Ca.

Railroad: Southern Pacific

Date: 1969

Photographer: Stan Praisewater



click to enlarge
Location: Ferry St. - Martinez, Ca.

Date: June 19, 1953

Railroad: Southern Pacific

Photographer: Robert A. Campbell, Sr

Tony Johnson collection

-Martinez once had wigwags at all three grade crossings on the SP main. 2 of the 3 lasted until the late 1990's. This was the third that was  replaced during the 1950's. Also note the human flagman assisting the magnetic one. I would assume his job was lost when they installed the gates a couple years later.



click to enlarge
Recently installed  Magnetic Flagman at Goodwin Ave.

Location: Glendale, Ca.

Railroad: Southern Pacific

Date: 1920's

Photographer: Unknown - Automobile Club of  Southern California



click to enlarge
Early installation of a WRRS wigwag.

Location: Tecumseh, Michigan
(not entirely sure on location)

Railroad: Detroit, Toledo & Ironton

Date: January, 1932

Photographer: Unknown - Jerold Crawford collection



click to enlarge
SP 4449 with special Disney train for filming of "Tough Guys".

Location: Seacliff, Ca

Railroad: Southern Pacific

Date: March, 1986

Photographer: Jack Neville



click to enlarge
2 WRRS Autoflags in Ames, Iowa.

Location: Lincoln Way (US 69)

Railroad: C&NW (Des Moines Branch)

Date: 1971

Photographer: Jerold Crawford

Crossing upgraded in 1973. Anyone remember Robo Carwashes?



click to enlarge Location: Stockton, Ca.

Railroad: AT&SF

Date: 1980

Photographer: Jerold Crawford





click to enlarge
Early Magnetic Flagman installation.

Location: Kennydale, WA (near Seattle)

Railroad: Northern Pacific

Date: early 1920's

Photographer: Unknown

Richard Wilkens collection



click to enlarge
Early Magnetic Flagman installation.

Location: Kennydale, WA (near Seattle)

Railroad: Northern Pacific

Date: early 1920's

Photographer: Unknown

Richard Wilkens collection



click to enlarge
The pair of upper quadrant signals is at Richmond Road in Susanville.  I am facing southeast.  This crossing is just west of the depot.  The signals lasted several years longer until the SP cut back the branch by a mile or so.  The locomotive is from the Susanville Local from Wendel.  It comes this far west just to access the runaround track.

Railroad: Southern Pacific

Photographer: Stan Praisewater

Date: 1971



click to enlarge
Taken at the Highway 36 crossing of the Western Pacific Highline, just north of Westwood.  This highway runs between Red Bluff and Susanville, and in the picture, we are facing east.  Technically, the track belongs to the SP and this is an SP crossing.  It is the very end of SP's Westwood Branch, but the part beyond Susanville had been abandoned, so the SP couldn't even access it.  WP eventually bought the 6 or 8 miles it uses.  The wig wags were gone a year or two later and now the track is busier than ever as the BNSF Inside Gateway.

Photographer: Stan Praisewater

Date: 1969





click to enlarge
SP (UP Warm Springs Subdivision) at N. 5th St. in San Jose, Ca.
Note wigwag in center median.

Photographer: Stan Praisewater

Date: 1968



click to enlarge
Same as above, different angle.

Note very short cantilever. This may have been a one of a kind installation.


click to enlarge
SP Long Beach Branch. Unknown crossing. Near Port of Long Beach. Magnetic Signal Company "Peach Basket".

Photographer: Alan Newton

Date: 12/7/75



click to enlarge

Dave Clark sends in these interesting photos from the archives of the MN/DOT. Apparently a  photographer was sent out to record the current grade crossing signals before the crossing was upgraded. These photos date back to January 1963. There were two crossings, side by side and linked to an overlapping circuit.

Photographer: unknown
MN/DOT

Rochester, MN -
11th Ave. N.E., looking North

Date: 1/63

Contributed by Dave Clark



click to enlarge
Photographer: unknown
MN/DOT

Rochester, MN -
9th Ave. N.E., looking South

Date: 1/63

Contributed by Dave Clark



click to enlarge
Orange St. Crossing of the Santa Fe in downtown Redlands, Ca. Notice wigwag behind the group. Looks to be around 1920.

Photographer: unknown
Date: early 20's

Archives, A.K. Smiley Public Library
Contributed by Nathan Gonzales



click to enlarge
34th street crossing Amarillo, Texas July 10, 1955. Train is Eastern Express-- Lubbock, TX connection with the eastbound San Francisco Chief. This wigwag (and its partner on the other side of the tracks) guarded the busy mainline crossing until the state built an overpass
over the tracks in the late 1970s.

Photographer: J. Howard Miller
Date: July, 1955

Collection of Jay Miller



click to enlarge
An AC Transit bus drops off passengers next to the wigwag that once guarded the 105th street crossing at East 14th Street in Oakland Ca. This was once part of the old SP Stonehurst Branch (now abandoned).

Photographer: unknown
Date: mid 1960's (can't you tell?)

collection of Andy Goddard



click to enlarge
SP wigwag at Chandler, AZ. Note the use of a ladder instead of stirrups (pole steps) and original type MSCo base. Most SP wigwags did not have crossbucks mounted to mast.

photographer: Tom Fassett
Date: 10-83

status: retired late '80's.



click to enlarge
Old postcard view of downtown Turlock, Ca around 1940. Note the double set of Magnetic Flagmen.

Photographer: unknown
Date: 1940

Larry Granfield collection
