Canadian National Railways

Ten-Wheeler 4-6-0

F-1-b 1008 (ex CGR 4528) MLW 51131 1912
Kent Junction, NS July 1, 1940 Al Paterson/Bud Laws Collection

F-1-b 1009 in better days hauling tourists on the Salem & Hillsborough,.
Hillsborough, NB. July 10, 1988 Roger Lalonde
Ex CNR 1165:2, 1009 ex CGR 4529 nee O'Brien, McDougall & O'Gorman 15
Cyl. 18" x 24" Drv. 51" Press. 160 lbs. 21,000 t.e. MLW 51132 5/1912

Donated June 1960 CRHA Delson. Loaned 1983 CRHA New Brunswick Division.

F-1-b 1011 ex CGR 4531 MLW 49919 1911
Moncton, NB 7/1935 L.A.Stuckey/Jim Booth Collection

G-10-a 1055 (ex CNoR 1055) Cyl. 19" x 24" Drv. 56" Press. 180 lbs. t.e. 21%
Looking fresh out of the back shop. James Adams/Bud Laws Collection
Note the marker on back of tender indicating it is about to run light engine.
Truro, NS September 25, 1944

G-16-a 1111-1160 (50 engines)

Cyl. 20" x 24" Drv. 57" Press. 180 lb. t.e 25%

G-16-a 1111 (ex CNoR 1111) MLW #50809 1912
Campbellton, NB 5/01/1945 L.A.Stuckey/Bud_Laws_Collection

1112 is at Railway Museum of Eastern Ontario in Smiths Falls.
Previously at CRM Delson as QNS&L 1112

1119 dead with rods off. The steam era is over. Montreal 9/04/1960 Bud Laws Collection

1138 Picton, NS November 8, 1957 Al Paterson Bud Laws Collection

1139 Unknown location. Bud Laws Collection

1140 Toronto 7/1953 Bud Laws Collection

1158 (ex CNoR 1158) Cyl. 20" x 24" Drv. 57" Press. 180 lb. t.e 25% MLW #52587 4/1913
Displayed at Western Development Museum, North Battleford, SK Roman Litarchuk

G-20

G-20-a 1174 (ex GTR 1646) Cyl. 21" x 26" Drv. 56" Press. 170 lbs. t.e. 30% Baldwin 15919 1898
Unknown location. Bud Laws Collection

H-3

H-3-a 1207 (ex CNoR 1207) Cyl.18" x 24" Drv. 62" Press. 200lbs. t.e. 21% Brooks 27214 1903
Clinton, Ont. 9/26/1942 Fred V. Stephens/Gary Everhart Collection


H-3-b 1212 (ex CNoR 1212) Cyl.18" x 24" Drv. 62" Press. 200 lbs. t.e. 21% MLW #39783 1906
Palmerston, Ont. August 4, 1941 Bud Laws Collection

H-4

H-4-a 1223 ex CNoR 1223 Cyl. 18" x 24" Drv. 63" Press 200 lbs t.e.21%
(1221-1230 10 engs.) CLC 738 1906 Re# 1520:2nd 8/1956
North Bay, Ont. 7/20/1940 L.A.Stuckey/Jim Booth Collection

H-4-b 1238 Ex CNoR same specs as H-4-a sub-class
(1231-1245 15 engs.) CLC 758 1907
Looks like a work train doing track work.
Sunnyside (Toronto) August 30, 1941 Al Paterson

H-6

H-6-b 1270 (ex CNoR 1270) MLW 1905 Note Belpaire boiler. Saskatoon September 14, 1936
Al Paterson/Bud Laws Collection

H-6-b 1274 re# 1/1957 ex CNOR 1274 nee 213 MLW 30563 7/1905

Working regular yard job. Reddit, ON May 1955 Robert Wanner

CNR spec sheet

Saskatoon Bud Laws Collection

H-6-c 1303 Ex CNoR 1303 (45 engs 1278-1322) Cyl various Drv. 63" Press 200 lbs. t.e. 28-30%
MLW 44790 1908 re# 1525:2nd 10/1956 Palmerston, Ont. July 22, 1956
Al Paterson/Bud Laws Collection

1315 Lots of black smoke! Bud Laws Collection

1320 John Adams/Bud Laws Collection

1321 (ex CNoR 1321) Re# 1530:2nd 10/1956 MLW 48317 1910
Palmerston 7/19/1956 L.A.Stuckey/Jim Booth Collection

H-6-c 1321 (ex CNoR 1321) Cyl. 22" x 26" Drv. 63" Press. 200 lbs. t.e. 28% MLW #48317 1910
Stratford, Ontario July 1, 1940 Bud Laws Collection

It is interesting to note the many differences between 1321 above and 1376 below,
both of the same class, both built by Montreal Locomotive Works and both for Canadian Northern.
1321 has inside admission valve gear. Location of headlights, air reservoir, tender coal boards, ladder and trucks.

1322 running Extra in a nice branchline scene in 1955 at Collingwood, Ont. Note the unusual water column.
Ex CNoR 1322 last H-6-c (1278-1322 45 engines) MLW 48318 1910. Renumbered 1531 2nd 3/1958.
Note too CN 51452 water tender in work service. Jim Parker

H-6-d 1330 (ex CNoR 1330) 1323-1342 20 engines
Cyl. 22" x 26" Drv. 63" Press. 180 lbs. t.e. 30% MLW 49883 1910
Winnipeg 9/27/1957 John Lameck/Sam Beck Collection

1333 (ex CNoR 1333) MLW 49886 1911 Neepawa, Man. 5/12/1954
L.A.Stuckey/Jim Booth Collection

1334 Saskatoon June 30, 1952 Al Paterson/Bud Laws Collection

H-6-d 1340 (ex CNoR 1340) Cyl. 22" x 26" Drv. 63" Press. 180 lbs. t.e. 30% MLW 49893 1911
Montreal 3/29/1958 Joseph Testagrose Collection

H-6-f 1347 ex DW&P 1347 (1347-1351) Cyl. 22" x 26" Drv. 63" Press. 190 lbs. t.e. 28% Baldwin 36933 1911
Winnipeg 8/22/1948 Doug Cummings/Bud Laws Collection

H-6-f 1348 (ex DW&P 1348) Palmerston August 16, 1958 Al Paterson/Bud Laws Collection

H-6-g 1359 (ex CNoR 1359) 1354-1409 56 engines Cyl. 22" x 26" Drv. 63" Press. 180 lbs. t.e. 28% MLW 50783 1912
Saskatoon Ray Deschenes/Bud Laws Collection

H-6-g 1376 (ex CNoR 1376) MLW #50800 1912
Brandon, Manitoba. Un-dated. Bud Laws Collection

CNR 1389 (ex CNoR 1389) MLW 52646 1912

In this two sequence scene we see the fireman on top of the engine preparing to fill sand dome.
Another man is up on the coal tower by the sand fill pipe. Look at the cab roof and tender!
Did the man on the coal tower pull the chain too soon? Look below for end result!

More sand over the sand dome, boiler and cab front side. Once they left town no doubt sand was blowing all over!
Winnipeg 8/26/1959 Doug Cummings/Bud Laws Collection

1390 (Ex CNoR 1390) MLW 52647 1913 Renumbered 1576 2nd 8/1956

1391 (Ex CNoR 1391) MLW 52648 1913 Bud Laws Collection

1394 (Ex CNoR 1394) Montreal March 30, 1941 Al Paterson/Bud Laws Collection

1399 (Ex CNoR 1399) MLW 52594 1913 Bud Laws Collection

H-10

Cyl. 19" x 26" Drv. 63" Press. 200 lbs. t.e. 25%

H-10-a 1423 (ex GTP 600 one of 20) MLW #48032 1910
Armstrong, BC 1939 Bud Laws Collection

1427 (above) right and 1429 (below) left views of identical H-10-a sub.class engines.
Kamloops, BC October 17, 1940 Bud Laws Collection

1429 (ex GTP 606) Armstrong, BC August 1939 Bud Laws Collection

1430 with bell ringing! Armstrong October 1939 Bud Laws Collection

1432 at Armstrong. July 10,1941 Bud Laws Collection

Extra 1433 at Armstrong some time in 1939. Bud Laws Collection

1434 (ex GTP 611) MLW 48043 1910 Port Mann, BC 10/07/1938 J.Schick/Bud Laws Collection

An interesting scene with 1436 complete with bicycle and touring car. Armstrong in July 1936. Bud Laws Collection

Two views of 1443 first of 10 H-10's built by CLC (950) in 1910.
Armstrong November 22,1940 Bud Laws Collection

Another view of 1443 this time in warmer weather! Armstrong July 14,1941. Bud Laws Collection
Note water flowing from injector discharge pipe onto the ground instead of going into the boiler.
Note too marker lamp on back of tender along with white classification flags. This is a complete train!

H-10-a 1447 ex GTP 624 Cyl. 19" x 26" Drv. 63" Press. 200 lbs. t.e 25% CLC 954 1910
9/07/1959 Dauphin, Man. Joseph Testagrose Collection

1447 "rods down" Valley River, Manitoba October 11, 1957 Al Paterson/Bud Laws Collection

Extra 1448 with stock cars on head end of train. Armstrong. September 7, 1941 Bud Laws Collection

H-6-g 1532 ex 1324 8/1956 nee CNoR 1324 Cyl. 22" x 26" Drv. 63" Press. 180 lbs. t.e. 30% MLW 49877 1910
Mildmay, Ont. 10/17/1958 Joseph Testagrose Collection

H-6-g 1564 ex 1374 8/1956 nee CNoR 1374 Cyl. 22" x 26" Drv. 63" Press. 180 lbs. t.e. 30% MLW 50798 1912
Palmerston, Ont. 5/14/1958 Joseph Testagrose Collection

1573 just coaled up. Note man on top of tender.
Spadina circa 1930 (scrapped 2/1936). Al Paterson Bud Laws Collection

I-6-b 1573 (ex GTR 340) MLW 29857 1904 Brockville, ON c.1926

I-7-a 1581 (ex GTR 335) Cyl. 22x26 Drv.69" Press. 200 lbs. t.e. 31% Schenectady #29634 1904

I-8-a subclass

Cyl. 21" x 26" Drv. 73" Press. 175 lbs. t.e. 23%

1589-1598 (10) ex GTR 400-409 MLW 1906
1599-1608 (10) ex GTR 410-419 Schenectady 1906
1609-1618 (10) ex GTR 420-429 GTR 1907
1619-1628 (10) ex GTR 430-439 Baldwin 1907

I-8-a 1589 (ex GTR 400) Cyl. 21x26 Drv. 73" Press. 175 lbs. t.e. 23% MLW 39538 1906
Location and date unknown. Retired 12/1935

1591 (ex GTR 402) Date and location unknown. Retired 12/1935 Bud Laws Collection

1609 (ex GTR 420) dead line London May 1937 Scrapped 7/1941
